Ferrite Magnets

Ceramic Magnets / Ferrite Magnets: Discs, Blocks and Rings

Permanent ferrite magnets, often known as ceramic magnets, are frequently used as a cheap alternative to rare-earth magnets when strength is not critical. The most common uses of ferrite magnets include fridge magnets, brakes, clamps, loudspeakers, security systems, medical instruments and a wide range of other applications.

Ferrite is a ceramic material, made using iron oxide and small amounts of other metallic elements, such as strontium, nickel, manganese and zinc. Ferrite is electrically non-conductive, which means ferrite magnets act as insulators, and can either be magnetised (hard ferrite) or attracted to a magnet (soft ferrite).

Hard ferrite, also called sintered ferrite, is the permanent magnet form of the material and is difficult to demagnetise. They’re often used for loudspeakers, refrigerator magnets and electrical motors. Soft ferrites, on the other hand, are conductors of magnetic fields and can easily change their magnetisation. They’re often used as magnetic cores (known as ferrite cores) in the electronics industry, useful for transformers, high-frequency inductors and microwaves.

Ferrite Magnets / Hard Ferrite

We specialize in industrial Ceramic magnets for sale online carries a large inventory of ceramic disc, block (rectangular & square), and ring magnets, available for immediate purchase in a wide range of shapes and sizes. Ferrite magnets, also known as ceramic magnets. The Ferrite permanent magnet is also known as a Ceramic Magnet and even as hard ferrite magnet. We offer a large inventory of ceramic disc, block (rectangular & square), and ring magnets.

Hard ferrite ceramic (Hard Ferrite) magnets were developed in the 1960’s as a low cost alternative to metallic magnets. Compared with other permanent magnet materials they exhibit low energy and relatively brittle and hard, ferrite magnets have won wide acceptance due to their good resistance to demagnetization, excellent corrosion resistance and low price per pound. It is the first choice for most types of DC motors, magnetic separators, magnetic resonance imaging and automotive sensor.

Buy ceramic magnets on-line today. Magnosphere carries a large inventory of ceramic disc, block (rectangular & square), and ring magnets, available for immediate purchase in a wide range of shapes and sizes.

Ceramic magnets (also known as "Ferrite" magnets) are part of the permanent magnet family, and the lowest cost, hard magnets available today. Ceramic magnets are used for many consumer & commercial applications such as craft projects, refrigerator magnets, badge holders, latches, display boards, motors, lifting magnets, science projects, toys, games, POP displays, advertising giveaways & much more. We can also custom manufacture ceramic magnets to fit your exact specifications using our in-house global manufacturing facilities and experienced team of engineers.

Ferrite

Hard ferrite ceramic (Hard Ferrite) magnets were developed in the 1960’s as a low cost alternative to metallic magnets. Compared with other permanent magnet materials they exhibit low energy and relatively brittle and hard, ferrite magnets have won wide acceptance due to their good resistance to demagnetization, excellent corrosion resistance and low price per pound. It is the first choice for most types of DC motors, magnetic separators, magnetic resonance imaging and automotive sensor.

• What are the main characteristics for ceramic magnets? Ceramic magnets are medium in magnetic strength, and can be used at fairly high temperatures. They are low cost, making them ideal for applications such as automotive sensors, magnetic separators, craft projects, badge holders, latches, display boards, science projects, toys, games & more.
• What grades & shapes are available for ceramic magnets? Grades 5 (most commonly used) through 8 are available in disc, block (rectangle & square) and ring shapes, and can be custom manufactured to meet your specialty requirements.
• What are the temperature constraints for ceramic magnets? Ceramic magnets can be used at fairly high temperatures, although their magnetic properties drop with temperature. At 175°C (350° F), approximately 75% of their room temperature magnetic properties are retained. How are magnets rated? Magnets are typically rated by their residual induction, coercive force & maximum energy product. Click here for more details (section 4.0). This refers to the maximum strength that the magnetic material can be magnetized to.
• What are some common applications for ceramic magnets? Common applications for ceramic magnets include raft projects, refrigerator magnets, badge holders, latches, display boards, loudspeakers, security systems, motors, generators & alternators, lifting magnets, eddy current devices, brakes, clamps, switches & relays, sweeper magnets, science projects, toys, games, motors, magnetic couplings, POP displays, advertising giveaways, promotional items, novelties & more.
• Are there machining constraints for ceramic magnets? Ceramic magnets require special machining techniques, and should be machined in an “un-magnetized” state. We are fully equipped to machine these materials to your specifications, just let us know what you are looking for by sending us a special request.
• Are surface treatments required for ceramic magnets? Ceramic magnets do not need to be protected for surface rust. A thin film of magnet powder on the surface is common.
• What are some bonding applications for ceramic magnets? Ceramic magnets are often assembled into products using "superglues" such as Loctite 325 or other epoxies. Please always ensure that bonding surfaces are clean and dry prior to bonding.
• What are some bonding applications for ceramic magnets? Ceramic magnets are often assembled into products using "superglues" such as Loctite 325 or other epoxies. Please always ensure that bonding surfaces are clean and dry prior to bonding.

Available Grades of Ceramic Magnets:

Magnosphere offers Ceramic Magnets in a variety of grades, including Ceramic 1, Ceramic 5, Ceramic 8, and Ceramic 8B in strengths ranging from 1.05 – 3.8 MGOe.

Corrosion Resistance:

Ceramic magnets are very resistant to corrosion. Coatings can be applied for cosmetic reasons or to reduce the fine, ferrite powder which is associated with ceramic magnets.

Temperature Effects:

Ceramic Magnets are susceptible to demagnetization when exposed to temperature extremes. There are grades which have better resistance to high and low temperatures, but several factors will dictate the performance of a ferrite magnet.

Magnetization Options:

Although most commercial magnets are anistropic, which means they have a preferred direction of magnetization, various pole configurations can be achieved without conflicting with a Ceramic Magnet’s orientation.

Compliance and Intellectual Property Considerations:

Ceramic magnets manufactured by Magnosphere are compliant with Intellectual Property Rights, Environmental Restrictions, and Conflict Mineral usage.

• Dodd Frank Wall Street Reform Act (Section 1502
• RoHS, RoHS II and REACH

Handling and Storage of Ceramic Magnets:

Ceramic Magnets are very strong and brittle, requiring appropriate handling and packing to ensure safety and prevent damage.

Ceramic Magnet Manufacturing Methods:

Ceramic or Ferrite Magnets are produced by calcining a mixture of iron oxide and strontium carbonate to form a metallic oxide. A multiple stage milling operation reduces the calcined material to a small particle size. The powder is then compacted in a die by one of two methods. In the first method, the powder is compacted dry which develops an isotropic magnet with weaker magnetic properties, but with better dimensional tolerances. Oftentimes, a dry pressed magnet does not require finish grinding. In the second method, the powder is mixed with water to form slurry. The slurry is compacted in a die in the presence of a magnetic field. The applied field creates an anisotropic magnet which exhibits superior magnetic properties, but usually requires finish grinding. The compacted parts which approximate the finished geometry are then sintered at high temperatures to achieve the final fusion of the individual particles. Final shaping is achieved by diamond abrasives. Usually the pole faces of the ceramic (ferrite) magnets will be ground and the remaining surfaces will exhibit “as sintered” tolerances and physical characteristics.
